The development of direct electron detectors has played a key role in low-dose electron microscopy imaging applications. Monolithic active-pixel sensor (MAPS) detectors are currently widely applied for cryogenic electron microscopy (cryo-EM); however, they have best performance at 300 kV, have relatively low read-out speed and only work in imaging mode. Hybrid pixel detectors (HPDs) can operate at any energy, have a higher DQE at lower voltage, have unprecedented high time resolution, and can operate in both imaging and diffraction modes. This could make them well-suited for novel low-dose life-science applications, such as cryo-ptychography, iDPC, and liquid cell imaging. Timepix3 is not frame-based, but truly event-based, and can record individual hits with 1.56 ns time resolution. Here, we present the integration of such a detector into a cryo-EM workflow and demonstrate that it can be used for automated data collection on biological specimens. The performance of the detector in terms of MTF and DQE has been investigated at 200 kV and we studied the effect of deterministic blur. We describe a single-particle analysis structure of 3 Å resolution and compare it with Falcon3 data collected using the same microscope. These studies could pave the way towards more dose efficient single-particle techniques.
Date & Time: 2023.6.28 10:00AM
Location: Conference Room 109, Thermal Engineering Building
Abstract
The development of direct electron detectors has played a key role in low-dose electron microscopy imaging applications. Monolithic active-pixel sensor (MAPS) detectors are currently widely applied for cryogenic electron microscopy (cryo-EM); however, they have best performance at 300 kV, have relatively low read-out speed and only work in imaging mode. Hybrid pixel detectors (HPDs) can operate at any energy, have a higher DQE at lower voltage, have unprecedented high time resolution, and can operate in both imaging and diffraction modes. This could make them well-suited for novel low-dose life-science applications, such as cryo-ptychography, iDPC, and liquid cell imaging. Timepix3 is not frame-based, but truly event-based, and can record individual hits with 1.56 ns time resolution. Here, we present the integration of such a detector into a cryo-EM workflow and demonstrate that it can be used for automated data collection on biological specimens. The performance of the detector in terms of MTF and DQE has been investigated at 200 kV and we studied the effect of deterministic blur. We describe a single-particle analysis structure of 3 Å resolution and compare it with Falcon3 data collected using the same microscope. These studies could pave the way towards more dose efficient single-particle techniques.
Lecturer
Yue Zhang
Born on June 19, 1993, in Hubei, China, Yue Zhang spent most of his life there until he moved to Jinan in 2011 to pursue his bachelor's degree. In 2015, he graduated with a diploma in Energy and Environmental Engineering from Shandong University and subsequently moved to Delft, the Netherlands to continue his graduate studies at the Delft University of Technology. He completed his Master's degree in Sustainable Energy Engineering in 2017 and then began working as a researcher in the university, designing and fabricating in-situ TEM nanochips under the supervision of Prof. Henny Zandbergen.
